IXTA 7N60P
IXTP 7N60P
Symbol
Test Conditions
Characteristic Values
(T J = 25 ° C, unless otherwise specified)
Min. Typ. Max.
TO-220 (IXTP) Outline
g fs
C iss
C oss
C rss
t d(on)
t r
t d(off)
V DS = 10 V; I D = 0.5 I D25 , pulse test
V GS = 0 V, V DS = 25 V, f = 1 MHz
V GS = 10 V, V DS = 0.5 V DSS , I D = I D25
R G = 18 ? (External)
4
7
1080
110
11
20
27
65
S
pF
pF
pF
ns
ns
ns
t f
Q g(on)
Q gs
Q gd
V GS = 10 V, V DS = 0.5 V DSS , I D = 0.5 I D25
26
20
7
7
ns
nC
nC
nC
Pins: 1 - Gate
2 - Drain
R thJC
0.83 ° C/W
R thCS
(TO-220)
0.25
° C/W
Source-Drain Diode
Characteristic Values
Symbol
Test Conditions
(T J = 25 ° C, unless otherwise specified)
Min. Typ. Max.
I S
V GS = 0 V
7
A
I SM
V SD
t rr
Repetitive
I F = I S , V GS = 0 V,
Pulse test, t ≤ 300 μ s, duty cycle d ≤ 2 %
I F = 7 A, V GS = 0 V
-di/dt = 100 A/ μ s, V R = 100 V
500
14
1.5
A
V
ns
TO-263 (IXTA) Outline
Dim.
Millimeter
Inches
Min. Max.
Min. Max.
A
A1
b
b2
c
c2
D
D1
E
E1
e
L
L1
L2
L3
L4
R
4.06
2.03
0.51
1.14
0.46
1.14
8.64
7.11
9.65
6.86
2.54
14.61
2.29
1.02
1.27
0
0.46
4.83
2.79
0.99
1.40
0.74
1.40
9.65
8.13
10.29
8.13
BSC
15.88
2.79
1.40
1.78
0.38
0.74
.160
.080
.020
.045
.018
.045
.340
.280
.380
.270
.100
.575
.090
.040
.050
0
.018
.190
.110
.039
.055
.029
.055
.380
.320
.405
.320
BSC
.625
.110
.055
.070
.015
.029
IXYS reserves the right to change limits, test conditions, and dimensions.
IXYS MOSFETs and IGBTs are covered by 4,835,592
4,931,844
5,049,961
5,237,481
6,162,665
6,404,065 B1
6,683,344 6,727,585
one or moreof the following U.S. patents:
4,850,072
4,881,106
5,017,508
5,034,796
5,063,307
5,187,117
5,381,025
5,486,715
6,259,123 B1
6,306,728 B1
6,534,343
6,583,505
6,710,405B2 6,759,692
6,710,463 6,771,478 B2
